• MULTI PLUS Now Available

  • iRIS Compatible

  • High intensity Ceramic Light Engine (LED) Technology

  • Market leading brightness and efficiency

  • Available in Blue, White, Multi Colour Or MULTI Plus

  • Direct-Connect Patented detachable electrical connection

  • Choice of rim colours including, Clear (standard), White, Grey or Black

  • Suitable for Concrete and Fibreglass pools

  • IPX8 waterproof rating

  • Designed and manufactured in Australia




TECHNICAL SPECIFICATIONS

ModelQuantum (WN)
Light source Ceramic Light Engine (LED)
Colours MULTIPLUS (RGB+W)
  • Static4000K True WhiteAquaDeep BlueMagentaRedLimeGreen
  • ShowsOceanic Views, Transcendence, Outback Australia, Spring Equinox
SINGLE COLOURS
  • Deep Blue (457nm)Legacy Blue (465nm)4000K True White3000K Warm White
Dimming Available on MULTIPLUS models when paired with an iRIS lighting controller
Rim colours Transparent / Grey / Black / White
Controller compatibility
Spa Electrics Wall switch operation · iRIS lighting controllers
Third-party automation

Full third-party controller compatibility is available with MULTIPLUS models only.

  • AstralPool Connect 10®, Connect Lite/+®, Halo Lite 2/4®, Halo Hub®, Viron EQ Chlorinator®
  • Pentair IntelliTouch®, EasyTouch®, IntelliCentre®
  • Zodiac/Jandy RS/Z4® (F/W Rev ‘R’ to current), Aqualink TRI/M8®, eXO iQ Chlorinator®
  • Hayward OmniLogic®, OmniDirect®, OmniHUB®, Omni PL®
  • Dontek Aquatek®
  • INSNRG Vi Chlorinator®
  • SplashMe Automation Controller®
  • Theralux Pool+ Manager®

Further compatibility information and setup instructions are in our controller guides, or contact us if you're unsure.
Installation & electrical
Suitability
  • WNC Concrete
  • WNF Fibreglass
Voltage 12V AC
Power 12W
IP rating IPX8
Operating temperature 0°C to +40°C ambient
Care & warranty
Usage Run the light for at least 30 minutes per week, all year round
Warranty 12 month manufacturer’s warranty
Product Manuals
